285785 Washer Direct Drive Clutch Assembly Compatible with Whirlpool Kenmore KitchenAid Maytag Roper Estate Inglis Amana Admiral, Replaces AP3094537 PS334641 285331 3351342 3946794 3951311 285785VP 62699 63174 3350015 3350114 3350115
  • 285785_1
  • 285785_2
  • 285785_3
  • 285785_4
Factory Certified
Free Ship $49+
30-Day Returns
1-Year Warranty
Compatible Brands
Compatible Models
Showing 38 compatible models
Aftermarket Replacement · Factory Direct
OEM-compatible part built to original specifications. Not manufactured by or affiliated with the original equipment brand.

285785 Washer Direct Drive Clutch Assembly Compatible with Whirlpool Kenmore KitchenAid Maytag Roper Estate Inglis Amana Admiral, Replaces AP3094537 PS334641 285331 3351342 3946794 3951311 285785VP 62699 63174 3350015 3350114 3350115

SKU: 285785
Order within --:-- to ship today
Repair Time45-60 Minutes
DifficultyModerate
DIY FriendlyYes
Tools Needed
Socket SetRatchetPliersPhillips Screwdriver
Qty
Ships from China · 10–20 business days
No sales tax outside CA
or
285785 Washer Direct Drive Clutch Assembly Compatible with Whirlpool Kenmore KitchenAid Maytag Roper Estate Inglis Amana Admiral, Replaces AP3094537 PS334641 285331 3351342 3946794 3951311 285785VP 62699 63174 3350015 3350114 3350115
In Stock

This Part Fixes These Problems

Pumps But Will Not Spin

Worn pads cannot engage the spin basket — motor runs and drains but tub will not rotate

Spins Slowly

Partially worn pads slip under load preventing full spin speed

Burning Smell

Worn pads generate friction heat and rubber odor during spin

Excessive Noise

Cracked brake cam driver creates banging or impact sound during spin

Repair Guides

How to Replace W10613606 Compressor Start Device & Capacitor on Whirlpool Refrigerator — Step-by-Step
May 31, 2026
How to Replace W10846539 Refrigerator Evaporator Fan Motor on Whirlpool Fridge — Step-by-Step
May 31, 2026
Samsung & Kenmore Dryer Idler Pulley Assembly Parts — Models & Compatibility
May 31, 2026
OEM vs Aftermarket Drum Front Glide Kit for Whirlpool & Maytag: Honest Comparison (12002126)
May 31, 2026
Whirlpool, Maytag & KitchenAid Refrigerator Defrost Thermostat Parts — Models & Compatibility
May 31, 2026

Product Description

Why Choose Our 285785 Washer Direct Drive Clutch Assembly?

🔧
Built to OEM SpecificationsBrake cam driver geometry, clutch pad diameter, spring dimensions, and retaining clip design all match the original Whirlpool 285785 spec. Drops onto the same transmission shaft in the same orientation — no measurement, no modification.
⚡
Both Springs Included — One Kit Covers All SizesBlue spring for standard large-capacity washers, green spring for compact models. Most competitors include only one. We include both so you install the correct spring for your machine and keep the other as a spare.
🛠️
Solid DIY Job — 45 to 60 MinutesTip the washer, pull the transmission, swap the clutch at the base. More involved than a filter swap but well within DIY range with a socket set. Watch one walkthrough video before starting — the disassembly sequence matters and saves you from reassembling twice.
🏭
Factory Direct — No Middleman MarkupA repair an appliance tech bills $200-300 for is a $25 part and an afternoon of your time. We ship direct from our facility — no distributor, no retail markup.
✅
Fits 10+ Brands — 1-Year WarrantyCompatible with Whirlpool, Kenmore, KitchenAid, Maytag, Roper, Estate, Inglis, Amana, Admiral, Crosley, and Magic Chef direct-drive top-load washers. Direct-drive only. 1-year warranty, 30-day returns.

💡 Pro Tip: Is the Clutch Your Problem?

Your part is likely the culprit if you notice any of the following:

⚠️ Tub spins slowly or cannot reach full spin speed

⚠️ Tub does not spin at all during the spin cycle

⚠️ Burning rubber smell during or after spin

⚠️ Loud banging or clunking during spin — impact noise, not vibration

During spin, open the lid momentarily. A healthy clutch decelerates the tub smoothly. If the tub stops abruptly, slows unevenly, or you smell burning rubber, the clutch pads are gone. Confirm by pulling the transmission and inspecting the clutch band — worn pads will be visibly thin or glazed.

📦 What's in the Box

✅ 1x Clutch Assembly

✅ 1x Brake Cam Driver

✅ 1x Blue Spring (large capacity)

✅ 1x Green Spring (compact)

✅ 1x Retaining Clip

Questions & Answers

How do I tell it is the clutch and not the motor coupling?
Answered by Support Team  ·  Sep 3, 2024
Check the coupling first — easier to access and cheaper. It sits between motor and transmission and shows visible cracks or a broken rubber center when failed. If the coupling looks good but you still get no spin with a burning smell, the clutch is your answer.
Which spring do I use — blue or green?
Answered by Support Team  ·  Dec 15, 2023
Blue for standard large-capacity machines, green for compact. Both springs are in the kit. If unsure, look at the spring that came out with the old clutch or check your owner manual for drum capacity.
How do I confirm my machine is direct-drive?
Answered by Support Team  ·  Mar 1, 2025
Look underneath — direct-drive machines have the motor mounted directly to the pump and transmission with no belt. Whirlpool used this design from the mid-1980s through early 2010s. Inside the tub: agitator on a shaft with no visible belt means direct drive.
Does 285785 replace 3946794?
Answered by Support Team  ·  Apr 22, 2024
Yes. 3946794, 285331, 3351342, 3951311 and others on the list are all older cross-references for the same clutch design. Whirlpool updated the numbering; the physical component did not change.
Should I replace the motor coupling at the same time?
Answered by Support Team  ·  Aug 30, 2023
Most techs do both together since you are already pulling the transmission. The motor coupling is cheap and if it is marginal it will fail within a year anyway — saves you opening the machine a second time.

We typically respond within 1 business day. Include your appliance model number for the fastest answer.
