How to Replace W10836692 Upper Agitator on Whirlpool Top-Load Washer — Step-by-Step

Your Whirlpool top-loader isn't agitating like it used to. Clothes come out tangled in a wet ball, and that familiar back-and-forth motion feels weak or stops completely mid-cycle. Nine times out of ten, the upper agitator's worn down or the internal dogs have stripped out. The W10836692 upper agitator fixes this — and you can swap it yourself in about 15 minutes.

What You Need Before Starting

This is one of the easiest washer repairs you'll tackle. Here's what to grab:

• Flathead screwdriver
• Socket wrench with 7/16" socket
• Towel (to catch any residual water)

Repair Time: 15-20 minutes
Difficulty: Easy

Safety First

Unplug the washer before you start. Water and electricity don't mix, and even though you're working on a mechanical part, there's always residual water in the tub. Keep that towel handy — you'll likely see a few ounces drain when you pull the old agitator.

Step 1: Remove the Fabric Softener Dispenser Cap

Grab the cap on top of the agitator and pull straight up. It should pop off without much force. If it's stuck from detergent buildup, twist gently while pulling. Set it aside — you'll reuse this cap with the new agitator.

Step 2: Unscrew the Agitator Bolt

You'll see a 7/16" bolt in the center shaft. Use your socket wrench to remove it — turn counterclockwise. This bolt holds the entire upper agitator assembly in place. Don't lose it in the tub; set it somewhere safe.

Step 3: Lift Out the Old Upper Agitator

Grip both sides of the agitator and pull straight up with firm, steady pressure. It might resist at first — years of detergent and fabric softener create a slight seal. Rock it gently side to side if needed, but keep pulling upward. Once it clears the splines on the lower agitator, it'll lift free.

Step 4: Clean the Lower Agitator Splines

Before installing the new part, wipe down the splines on the lower agitator base with a damp cloth. Remove any gunk, lint, or detergent residue. This ensures the W10836692 seats properly and engages fully during wash cycles.

Step 5: Install the New W10836692 Agitator

Align the new agitator with the splines and press down firmly until it seats completely. You'll feel it drop into place. Reinstall the center bolt and tighten it snug — don't overtighten or you'll strip the threads. Snap the fabric softener cap back on top.

Testing After Installation

Plug the washer back in and run a small load on a normal cycle. Watch the agitator during the wash phase — it should move back and forth aggressively, creating that churning action. If it spins freely without gripping, double-check that the bolt is tight and the agitator seated fully on the splines.

Frequently Asked Questions

Will this agitator fit my Kenmore or Maytag washer?

Yes. The W10836692 works across Whirlpool, Maytag, Kenmore, and Amana top-loaders. Check your model number against the compatibility list — models like WTW4855HW0, MVWC416FW1, and 4KWTW5800JW0 all use this exact part. It replaces older part numbers AP5988691, W10680220, and 4363274.

What if the agitator bolt won't budge?

Spray penetrating oil around the bolt threads and let it sit for 10 minutes. The bolt can corrode slightly from moisture exposure. If it's really seized, use a breaker bar for extra leverage — but be careful not to round off the bolt head.

Can I replace just the upper agitator or do I need the lower part too?

Usually just the upper section fails. The W10836692 is the complete upper agitator assembly with internal dogs. If your lower agitator base is cracked or the splines are rounded off, you'll need both — but that's rare. Start with the upper and see if that solves your problem.
