Whirlpool Refrigerator Condenser Fan Motor Parts — Models & Compatibility

Your Whirlpool fridge is running, but something sounds off. Maybe it's a grinding noise from behind the lower kickplate, or a constant humming that wasn't there before. That's usually your condenser fan motor telling you it's on its way out. This hub covers the W10909387 condenser fan motor that fits dozens of Whirlpool, KitchenAid, Maytag, and Amana refrigerators — including the popular WRT318FMDW, WRF767SDHZ, and WRS571CIHZ series models.

Is This the Right Part for Your Model?

Before ordering, you'll need to confirm your exact model number. On most Whirlpool refrigerators, look inside the fresh food section along the left or right wall — there's usually a white sticker with your model and serial number printed on it. Some models have it on the ceiling of the fridge compartment instead. Cross-reference that number with our compatibility list below to make sure the W10909387 fits your unit.

About This Replacement Part

The condenser fan motor sits behind your refrigerator near the compressor, pulling air across the condenser coils to dissipate heat. When it starts failing, you'll hear it. Noisy operation is the most common symptom — anything from rattling and grinding to a high-pitched whine that gets louder over time. If the motor seizes completely, your fridge will run warmer because the condenser can't cool efficiently. The W10909387 replaces several older part numbers including W11127829, W10527155, and W10917708, so if you've got one of those listed on your old motor, this is your replacement. It's a direct-fit motor with mounting bracket included.

Compatible Whirlpool Series

This condenser fan motor works across multiple Whirlpool refrigerator platforms. You'll find it in side-by-side models, French door configurations, and top-mount fridges from roughly 2010 forward. The WRT318 series alone has at least five compatible variations (WRT318FMDW01, WRT318FMDW02, WRT318FMDW05, WRT318ZDW05), and the WRF767SDHZ French door models use this same motor. KitchenAid and Maytag branded units built on the same chassis also take this part — check your model number to confirm.

What Causes Condenser Fan Motor Failure?

Dust buildup is enemy number one. That fan pulls air constantly, and if you've got pets or live in a dusty area, the motor bearings work harder than they should. Eventually they dry out and start making noise. Voltage spikes can also kill the motor windings, especially during summer months when your compressor is cycling frequently. Once you hear grinding or the fan stops spinning entirely, replacement is your only option — these motors aren't serviceable.

Installation Overview

You'll be working behind the fridge, so pull it away from the wall and unplug it first. Remove the lower rear access panel (usually four screws), disconnect the wire harness from the old motor, unbolt the mounting bracket, and swap in the new motor. The whole job takes maybe 20 minutes if you've done it before, longer if it's your first time wrestling with those tight spaces. Make sure the fan blade spins freely after installation before you push the fridge back into place.

Price and Availability

The W10909387 typically runs around $191.99, which is reasonable given how many models it covers. Compare that to a service call where you're paying diagnostic fees plus labor — most techs charge $200 just to show up. If you're comfortable with basic tools, this is a straightforward DIY repair that pays for itself in saved labor costs.
