Frigidaire Washer Drive V-Belt Parts — Models & Compatibility

Your Frigidaire washer stopped mid-cycle, humming but not spinning? That burning rubber smell you're detecting isn't coming from the dryer — it's likely a worn drive belt slipping on the pulleys. The 134511600 drive V-belt connects your washer's motor to the transmission, and when it fails, you'll get pumping action but zero spin or agitation. This hub covers compatible Frigidaire, Kenmore, Gibson, and Westinghouse models that use this specific belt design.

Is This the Right Belt for Your Model?

Before ordering, you'll want to verify your model number matches our compatibility list below. On most Frigidaire front-loaders, look for the model tag inside the door frame or along the top rim under the lid. The number typically starts with GLWS, FGX, FEX, or FEZ. Cross-reference it with the models listed in this hub — we've confirmed fitment for over 20 specific variants including the GLWS1233AS series through GLWS1749AS series.

About This Replacement Drive Belt

The 134511600 is a ribbed V-belt that wraps around the motor pulley, idler pulley, and transmission pulley in a triangular configuration. Typical failure happens after 5-7 years of regular use — the rubber compounds harden, ribs crack, or the belt stretches beyond the idler's adjustment range. When it starts slipping, you'll hear the motor running but see no drum rotation. One user mentioned replacing "the idler pulley, drive belt, and snubber ring all at once" after finding step-by-step repair videos online. That's smart preventive maintenance since you're already accessing the same area. The belt itself measures approximately 51 inches in circumference with multi-groove ribbing on the inner surface for positive traction. It's designed to handle the high torque loads during spin cycles — up to 1200 RPM in some models — without stretching or jumping off the pulleys.

Common Symptoms of Belt Failure

Here's what you'll experience when this belt goes bad:

• Spins slowly — Belt slippage reduces drum speed, leaving clothes soaking wet
• Burning smell — Rubber friction against metal pulleys creates that distinctive odor
• Pumps but will not spin — Water drains fine, but the drum stays motionless
• Will not agitate — In models with belt-driven agitation, you'll lose that back-and-forth action
• Noisy operation — A loose belt flaps and slaps against the cabinet during cycles

Installation Overview

This is genuinely one of the easier washer repairs. You'll need basic tools: pliers, screwdrivers, and a socket set. Plan on 15-30 minutes if you're methodical. The trickiest part isn't the belt itself — it's getting the cabinet panels off without breaking the plastic clips. One DIYer noted they "replaced the spin bearing, tub seal, washer and drive belt since I had it all apart" and found YouTube videos "extremely helpful" for understanding how the agitator comes off. Pro tip: take photos with your phone as you disassemble. When you're staring at three pulleys and a new belt, those pictures become your roadmap for routing it correctly.

Why This Belt Fails

Drive belts don't last forever — they're a wear item like brake pads. Normal use causes gradual degradation: heat cycling makes the rubber brittle, detergent residue can accelerate chemical breakdown, and constant flexing around pulleys creates fatigue cracks in the ribs. If you've been overloading the washer (we've all done it), that extra strain shortens belt life significantly. A properly tensioned belt should have about 1/2 inch of deflection when you press the center span. More than that, and it's slipping. Less, and you're wearing out the motor and transmission bearings prematurely.

Compatible Model Reference

This 134511600 belt fits the following Frigidaire washer models. If yours isn't listed but shares a similar model number pattern, there's a good chance it'll work — Frigidaire used this belt design across multiple production years:

• GLWS1233AS1, GLWS1233AS2
• GLWS1339ES0, GLWS1339ES1, GLWS1339CC0
• GLWS1349AS1
• GLWS1649AS1
• GLWS1749AS4
• FGX831CS1, FGX831FS0
• FEX831CS0, FEX831FS0
• FEZ831AS1, FEZ831AS2

This part also replaces older part numbers AP3867042, PS1146950, 131686100, and 1156860. If your original belt has any of those numbers stamped on it, the 134511600 is your direct replacement.

What Comes in the Box

You're getting one replacement drive belt — that's it. No pulleys, no mounting hardware, no installation instructions (hence the YouTube videos). The belt arrives coiled in a protective bag. Before you start the repair, inspect it for any shipping damage or manufacturing defects. It should be uniformly black with clean, sharp ribs on the inner surface.

Pricing & Value

At $13.99, this belt costs about what you'd pay for two fancy coffees. Compare that to a $150+ service call where a tech does the exact same 20-minute job. The money you save buys the socket set you'll use for the repair — and every future appliance fix. Original Frigidaire belts from authorized dealers often run $25-30, so you're looking at genuine replacement quality at half the price.
