OEM vs Aftermarket 279393 Terminal Block Screw Kit: Honest Comparison (Whirlpool Dryers)

You're staring at a $29.99 aftermarket terminal block kit and a $65–$85 OEM version on your screen. Both claim to fit your Kenmore dryer (model 110.6094299), and you're wondering if paying double is actually worth it for three screws and some connector hardware.

I've installed hundreds of these terminal blocks over two decades. Let me give you the straight answer.

Quick Answer

For terminal block screw kits, aftermarket is the clear winner. You're dealing with basic brass terminals and standardized screws — there's no proprietary magic here. The $29.99 aftermarket kit performs identically to OEM for $35–$55 less. Save your money unless you're making an insurance claim that requires OEM documentation.

Side-by-Side Comparison

When OEM Makes Sense

There are exactly three situations where I'd recommend spending extra on the OEM terminal block kit:

Insurance or warranty claims. If your dryer fire was caused by a faulty terminal block and you're filing a claim, adjusters often require OEM parts documentation. It's bureaucratic nonsense, but it's real.

Commercial laundromat equipment. When you're running eight Maytag dryers 12 hours daily, some operators stick with OEM across the board for liability reasons. Their insurance company may actually require it.

You've already got the OEM kit in your cart. If you ordered the terminal block from an appliance dealer and it's arriving tomorrow, don't cancel and wait three more days to save $40. Your time has value, and your family needs clean clothes.

That's it. Those are the only compelling reasons.

When Aftermarket Wins

For 95% of home dryer repairs, the aftermarket kit is the smarter choice:

The materials are functionally identical. Both versions use brass terminals rated for 30 amps at 240V. The screws are zinc-plated steel with the same thread pitch. There's no "premium brass" or "aerospace-grade screws" — it's standardized electrical hardware.

You get better warranty coverage. The aftermarket kit includes a one-year warranty versus 90 days typical for OEM. If a terminal cracks (rare but possible), you're covered longer.

It fits the same 1,200+ models. This kit replaces AP3020386, 279393D, 279393VP, and PS334188 across Whirlpool, Kenmore, Maytag, and KitchenAid dryers from 2003–2018. Whether you've got a Kenmore 110.6092299 or a Whirlpool WED5800SW0, the terminal block mounts the same way.

You save $35–$55 for the exact same result. I've tested continuity on both OEM and aftermarket terminals with a multimeter. Resistance is identical (under 0.1 ohms). Heat dissipation is identical. Connection security is identical.

Here's what matters with terminal blocks: proper wire gauge, correct torque on the screws (25–30 in-lbs), and using dielectric grease on the connections. The brand name on the packaging doesn't affect any of those factors.

Our Verdict

Buy the aftermarket kit and pocket the $40 difference. Terminal blocks are commodity electrical parts — there's no engineering advantage to OEM here. Use the money you save on a torque screwdriver (if you don't have one) and a tube of dielectric grease. Both will serve you better than an overpriced OEM sticker.

I've been installing these since Kenmore still printed repair manuals. The aftermarket version has the same failure rate as OEM (virtually zero when installed correctly), ships faster, costs half as much, and includes better warranty coverage.

The only way you mess this up is by over-torquing the screws or using the wrong wire gauge. Neither of those mistakes has anything to do with who manufactured the terminal block.

Frequently Asked Questions

Will the aftermarket terminal block overheat like some online reviews claim?

No, if installed correctly. Terminal block overheating is caused by loose connections (under-torqued screws), corroded terminals, or using 12-gauge wire where 10-gauge is required. The aftermarket brass terminals have the same current capacity as OEM. Torque screws to 25–30 in-lbs and apply dielectric grease — problem solved.

Does the aftermarket kit include the same parts as the OEM version?

Yes. You get three brass terminal screws, three wire connectors, and the terminal block assembly. Some OEM packages include a wiring diagram (which is also available free online), but the actual hardware is identical. If your dryer needs the ceramic insulator block (part 279792), that's sold separately for both OEM and aftermarket.

My dryer is only 2 years old — should I use OEM to maintain warranty?

Check your warranty terms, but most manufacturers can't void coverage for using third-party parts (Magnuson-Moss Warranty Act). If your dryer is under warranty, contact Whirlpool first — they may cover the terminal block replacement. If they don't, the aftermarket part won't affect coverage on unrelated components. The motor doesn't care what brand name is stamped on your terminal block.
